Description
An 84-year-old woman sustained a periprosthetic left hip fracture after a fall, and underwent revision internal fixation with a long cephalomedullary nail, with the operation involving removal of the broken nail as well as reinsertion of a new cephalomedullary nail (InterTan, Smith & Nephew, Memphis, TN, USA) (figure 1). Approach was via lateral incisions to approach the femoral shaft as well as the piriformis entry point.
(A,B) Anteroposterior (AP) and lateral X-rays of a periprosthetic left hip fracture with cephalomedullary nail failure. (C,D) AP and lateral X-rays of revision cephalomedullary nail (InterTan, Smith & Nephew, Memphis, Tn, USA).
The patient’s preoperative haemoglobin was 139 g/L (normal 120–155 g/L). The operation itself was uncomplicated without notable blood loss. Day 1 postoperative haemoglobin was 108. The patient was discharged to rehabilitation 5 days after surgery. During the time of rehabilitation, the patient fell against her chair, and subsequently noticed pain with swelling at the surgical site. She was readmitted on day 14 after initial operation, with a haemoglobin of 92 g/L. The thigh haematoma began to grow in size with increasing pain and on day 15 the haemoglobin dropped to 72 g/L. The large haematoma in the left gluteal region was not associated with surgical wound site ooze or dehiscence.
CT scan demonstrated a 12×11×7 cm haematoma in the left gluteal region, with active haemorrhage from a pseudoaneurysm arising from the superior gluteal artery (SGA) (figure 2).
Axial CT scans, (A) precontrast image demonstrating a left gluteal haematoma, note that the patient had a recent contrast study and hence has contrast in the bladder, (B) arterial phase study demonstrating active site of extravasation (white arrow), (C) postcontrast portal venous phase study demonstrating pooling of contrast within the haematoma.
Attempt was made at ultrasound-guided direct compression, however a repeat CT angiogram demonstrated no effect on the contrast blush from the pseudoaneurysm.
The bleeding pseudoaneurysm was accessed via a retrograde right common iliac artery sheath. Embolisation was performed via 3/2 mm Tornado micro-coils (Cook Medical, Bloomingdale, IN, USA) and 500–700 μm contour polyvinyl embolisation particles (Boston Scientific, Marlborough, MA, USA) (figure 3). The patient was transfused with one unit packed red blood cells. Postprocedure haemoglobin was 84, with no further enlargement of the haematoma, or haemoglobin drop. The patient was discharged.
(A,B) Super-selective runs of the superior gluteal artery demonstrate the pseudoaneurysm, with extravasation of contrast causing a ‘blush’, as well as vessel irregularity as a result of vasospasm which is a physiological attempt at arresting the haemorrhage. (C,D) Postembolisation runs demonstrate coil and particle embolisation of the superior gluteal artery, and cessation of haemorrhage.
Vascular complications are a potentially life-threatening adverse event after hip fracture fixation. While pseudoaneurysms of the profundal femoris artery, due to the zone of injury and proximity to the femoral nail are well described, injury to the gluteal arteries as a result of internal fixation are very rare. To our knowledge there have only been three previously described case reports of injury to the SGA after hip fracture internal fixation with a cephalomedullary nail.1–3 Injury to the SGA can occur during guidewire insertion, reaming, as well as nail insertion. Previously described cases were primary procedures for hip fractures, while our case is the first described revision case resulting in SGA. Revision surgery can require more extensive dissection and instrumentation that can injure surrounding neurovascular structures.
Learning points
Vascular injury is a rare but potentially serious complication of hip fracture internal fixation.
Vascular injury should be considered in cases of postoperative haemoglobin level drop.
Investigation with CT angiogram is a useful modality to investigate sites of bleeding, which can guide angioembolisation.
Ethics statements
Patient consent for publication
Footnotes
Contributors MN- data collection, literature review, drafting manuscript, DN- data collection, drafting manuscript, JM- drafting manuscript, JV- performing procedure, drafting manuscript.
Funding The authors have not declared a specific grant for this research from any funding agency in the public, commercial or not-for-profit sectors.
Case reports provide a valuable learning resource for the scientific community and can indicate areas of interest for future research. They should not be used in isolation to guide treatment choices or public health policy.
Competing interests None declared.
Provenance and peer review Not commissioned; externally peer reviewed.
